PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine

PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine
PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine
PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine

Büyük resim :  PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine

Ürün ayrıntıları:
Menşe yeri: Çin
Marka adı: JIATUO CHINA
Sertifika: CE ISO
Model numarası: JTPET-150
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 Takım
Fiyat: Pazarlık edilebilir
Ambalaj bilgileri: Plastik film
Teslim süresi: 50-60 GÜN Müzakere edilecek
Ödeme koşulları: L/C, T/T
İletişim

PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine

Açıklama
Çekirdek Bileşenler: Motor, PLC, vites kutusu, vida Otomatik Sınıflandırma: Tam otomatik/yarı otomatik
Makine Test Raporu: Tedarik edilen Vida Stili: Tek vida ekstrüder
Sıcaklık Kontrolü: Tayvan Fotek Motor: SIMENS
Kontrol sistemleri: PLC Çin/İngilizce Kontrol Sistemi Ekstrüde edilmiş kayış sayısı: 6
Üretim kapasitesi: 580-620KGS Garanti: 1 Yıl
Vida çapı (mm): 150mm Kayış genişliği: 9-32mm
Kalınlık: 0,4-1,2 mm Uygulama kapsamı: Tuğla bahçesi, metal, çelik, alüminyum, bira fabrikası
Ekran Filtresi: iki yönlü silindir / tek silindirli Vida Malzemesi: 38CrMoALA
Vurgulamak:

PLC PET Strap Extrusion Line CE

,

SIMENS Motor PET Strap Extrusion Line

,

32mm PET Strap Making Machine OEM

PLC Control Plastic Steel Packing Polyester PET Strapping Tape Belt Making Machine 580-620KGS/H



PET strap production line configuration reference



Item Name Quantity
1 Dehumidification and drying system 1 set
2 Oil and dust filter 1 set
3 Horizontal mixer(5000L) 1 set
4 Pre-drying tower(5000L) 1 set
5 Screw Feeder 3 set
6 Barrel(5000L) 1 set
7 ¢150mm Extruding Machine 1 set
8 Melt pump 1 set
9 Single cylinder filter 1 set
10 PET Mould output 6straps 1 set
11 Cooling water tank 1 set
12 Stretching oven 1 set
13 Five roller gearbox 3 set
14 PLC electrical control system 1 set
15 Forming oven 1 set
16 Double disk winder

6 set



PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine 0



Application



PET belts production machine:



It is mainly suitable for packaging for various trades. The use of the product is convenient and it can adopt common steel fastening for connection. It also is suitable for various kinds of hand-operated of table packing machine and large auto-packaging machine of enterprises.





PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine 1

PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine 2



Process flow



PET packaging belt production line:



① feeding→② mixing raw materials→③ raw material pre-drying→④ vacuum dehumidification of raw materials→⑤ raw materials melting extrusion→⑥ material embryo expression(with embryo) cooling molding→⑦oven preheating→⑧first stretching→⑨second stretching→⑩embossing→⑪ oven tempering to set the shape→⑫ cooling → ⑬winding(finished product)



PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine 3PLC Control PET Strap Extrusion Line 580-620KGS/H PET Strap Making Machine 4
